BOLD Linkin 150 Ultimate Bike

Modello : 287344

BOLD Linkin 150 Ultimate Bike
BOLD Linkin 150 Ultimate Bike BOLD Linkin 150 Ultimate Bike

Caratteristiche principali

  • LINKIN Carbon HMX Frame
  • FOX 36 Float Factory, 150mm
  • FOX Nude 5T Factory EVOL
  • SRAM XX1 Eagle AXS / Wireless
  • Shimano XTR M9120 4 Piston Disc
  • DT Swiss XMC 1501 Spline CL
  • Syncros Hixon iC Carbon

1. Taglia

Tabella taglie

CHF9,899.00 40.0% Discount

CHF5,939.40

Acquista adesso
Specifiche
  • All’apice dell’innovazione, la BOLD LINKIN è tutta focalizzata sui dettagli tecnici ed estetici per sottolinearne la modernità e il design leader del settore. È creata da ciclisti appassionati e progettata per chi desidera un’esperienza di alto livello in termini di tecnologia e design.

    Notare che le specifiche delle bici sono soggette a cambiamenti senza alcun preavviso.

  • Telaio

    Bold Linkin 150 / Carbon HMX
    Integrated Suspension Technology / IST VP
    Vario Tech, Head angle and BB height / Syncros Cable Integration System
    BB92 / UDH Interface / 12x148mm with 55mm Chainline

  • Forcella

    FOX 36 Float Factory Grip 2 Air / Kashima
    HSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle
    44mm offset / tapered steerer
    150mm travel

  • Ammortizzatore posteriore

    FOX NUDE 5T Factory EVOL Trunnion
    Custom travel / geo adj.
    3 modes: Lockout-Traction Control-Descend
    Custom large Air volume / DPS / Kashima / Reb. Adj.
    Travel 150-100-Lockout / T185X55mm

  • comando remoto

    TracLoc Technology
    Rear Suspension & Dropper Remote
    3 Rear Suspension modes

  • Deragliatore posteriore

    SRAM XX1 Eagle AXS / 12 Speed
    Wireless Electronic Shift System

  • Leve del cambio

    SRAM Eagle AXS Rocker Controller

  • Guarnitura

    SRAM XX1 Eagle
    Carbon crankarm
    DUB / 55mm CL / 32T

  • Guidacatena

    Bold custom

  • Movimento Centrale

    SRAM DUB PF 92 MTB Wide / shell 41x92mm

  • Catena

    SRAM CN XX1 Eagle

  • Cassetta

    SRAM XX1 XG1299 / 10-52 T

  • Freni

    Shimano XTR M9120 4 Piston Disc

  • Disco del freno

    Shimano RT-MT900 CL / 203/F and 180/R

  • Manubrio

    Syncros Hixon iC Carbon
    Size S & M 15mm rise / Size L & XL 25mm rise
    back sweep 8° / 780mm
    Syncros Pro lock-on grips

  • Reggisella

    Syncros Duncan Dropper Post 1.5 34.9mm
    Size S 150mm / Size M 170mm / Size L & XL 200mm

  • Sella

    Syncros Tofino Regular 1.0
    Carbon rails

  • Serie sterzo

    Syncros - Acros Angle adjust & Cable Routing HS System
    +-0.6° head angle adjustment
    ZS56/28.6 – ZS56/40 MTB

  • Ruote

    DT Swiss XMC 1501 Spline CL
    F: 15x110mm, R: 12x148mm
    30mm Tubeless ready Carbon rim 28H / XD Driver
    Syncros Axle w/Removable Lever with Tool

  • Gomma anteriore

    Maxxis Minion DHF / 2.5" / 60TPI Foldable
    Tubeless Ready / EXO

  • Gomma posteriore

    Maxxis Minion DHF / 2.5" / 60TPI Foldable
    Tubeless Ready / EXO

  • Extra

    Save the Day Kit
    SRAM AXS Powerpack
    Syncros Fork Fender

  • Accessori

    Syncros Eco Sealant

  • Peso in kg (approx.)

    13Kg / 13.4kg
Uso
No Radar Chart Available Currently
Geometria
Geometry of BOLD Linkin 150 Ultimate Bike
S S M M L L XL XL
LOW BB Setting HIGH BB Setting LOW BB Setting HIGH BB Setting LOW BB Setting HIGH BB Setting LOW BB Setting HIGH BB Setting
A head tube angle 64.2 ° 64.7 ° 64.2 ° 64.6 ° 64.2 ° 64.6 ° 64.2 ° 64.6 °
B head tube length 90.0 mm 3.5 in 90.0 mm 3.5 in 105.0 mm 4.1 in 105.0 mm 4.1 in 120.0 mm 4.7 in 120.0 mm 4.7 in 135.0 mm 5.3 in 135.0 mm 5.3 in
C top tube horizontal 547.1 mm 21.5 in 545.5 mm 21.5 in 596.2 mm 23.5 in 594.5 mm 23.4 in 629.3 mm 24.8 in 627.5 mm 24.7 in 662.5 mm 26.1 in 660.7 mm 26.0 in
D standover height 683.0 mm 26.9 in 683.0 mm 26.9 in 715.0 mm 28.1 in 715.0 mm 28.1 in 740.0 mm 29.1 in 740.0 mm 29.1 in 766.0 mm 30.2 in 766.0 mm 30.2 in
E BB offset -35.2 mm -1.4 in -29.0 mm -1.1 in -35.1 mm -1.4 in -28.8 mm -1.1 in -35.1 mm -1.4 in -28.7 mm -1.1 in -35.0 mm -1.4 in -28.5 mm -1.1 in
F BB height 339.8 mm 13.4 in 346.0 mm 13.6 in 339.9 mm 13.4 in 346.2 mm 13.6 in 339.9 mm 13.4 in 346.3 mm 13.6 in 340.0 mm 13.4 in 346.5 mm 13.6 in
G wheel base 1,179.5 mm 46.4 in 1,181.0 mm 46.5 in 1,220.9 mm 48.1 in 1,222.4 mm 48.1 in 1,257.4 mm 49.5 in 1,258.9 mm 49.6 in 1,293.8 mm 50.9 in 1,295.3 mm 51.0 in
H BB center to toptube center
I BB center to top of seattube 365.0 mm 14.4 in 365.0 mm 14.4 in 395.0 mm 15.6 in 395.0 mm 15.6 in 425.0 mm 16.7 in 425.0 mm 16.7 in 455.0 mm 17.9 in 455.0 mm 17.9 in
J seat angle 78.3 ° 78.9 ° 77.3 ° 77.8 ° 77.3 ° 77.8 ° 77.3 ° 77.8 °
K chainstay 433.9 mm 17.1 in 435.1 mm 17.1 in 433.9 mm 17.1 in 435.2 mm 17.1 in 433.9 mm 17.1 in 435.2 mm 17.1 in 433.9 mm 17.1 in 435.2 mm 17.1 in
L reach 422.0 mm 16.6 in 427.1 mm 16.8 in 457.0 mm 18.0 in 462.0 mm 18.2 in 487.0 mm 19.2 in 491.9 mm 19.4 in 517.0 mm 20.4 in 521.8 mm 20.5 in
M stack 605.2 mm 23.8 in 601.7 mm 23.7 in 618.7 mm 24.4 in 615.0 mm 24.2 in 632.1 mm 24.9 in 628.3 mm 24.7 in 645.6 mm 25.4 in 641.7 mm 25.3 in
N stem length 40.0 mm 1.6 in 40.0 mm 1.6 in 40.0 mm 1.6 in 40.0 mm 1.6 in 40.0 mm 1.6 in 40.0 mm 1.6 in 40.0 mm 1.6 in 40.0 mm 1.6 in
0 trail 561.0 mm 5.2 in 561.0 mm 5.1 in 561.0 mm 5.2 in 129.1 mm 5.1 in 132.6 mm 5.2 in 129.2 mm 5.1 in 132.7 mm 5.2 in 5.1 in
P Fork length 236.0 mm 22.1 in 236.0 mm 22.1 in 276.0 mm 22.1 in 561.0 mm 22.1 in 561.0 mm 22.1 in 561.0 mm 22.1 in 561.0 mm 22.1 in 129.4 mm 22.1 in
Q Maximum Seatpost Insertion 236.0 mm 9.3 in 236.0 mm 9.3 in 276.0 mm 10.9 in 276.0 mm 10.9 in 301.0 mm 11.9 in 301.0 mm 11.9 in 320.0 mm 12.6 in 561.0 mm 12.6 in
R Crank Length 6.7 in 6.7 in 6.7 in 170.0 mm 6.7 in 170.0 mm 6.7 in 170.0 mm 6.7 in 170.0 mm 6.7 in 320.0 mm 6.7 in
